通過更近對市場的調查回訪我們發現，很多客戶對順酐的制備方法還不是了解的很明白，今天小編就將查閱的相關資料與大家分享一下，希望引起大家的重視，讓大家對順酐有一個深層次的了解。這樣大家在購買使用順酐時也能做到心中有數，不怕上當受騙，希望對大家有所啟發與幫助。
Through the recent market survey, we found that many customers don't understand the preparation method of maleic anhydride very well. Today, the editor will share the relevant information with you, hoping to attract your attention and let you have a deep understanding of maleic anhydride. In this way, when purchasing and using maleic anhydride, you can be aware of it, not afraid of being cheated, and hope to inspire and help you.
1. 苯氧化制
1. Manufacturer of benzene oxidation to maleic anhydride
將苯與空氣混合(苯為1%-1.4% )經換熱器預熱后，進人列管式催化反應器。在壓力為0.1-0.2MPa、溫度為350-400℃的反應條件下進行氧化反應，所得產物經兩臺換熱器、一臺冷卻器后，冷卻到接近露點(55―65℃)。冷卻后的反應物進入分離器，分離器底部得粗順酐，進入粗順酐罐。分離器頂部流出物進人洗滌塔，用水洗滌，塔頂為多余空氣和未反應的苯，苯可用吸附回收。洗滌塔塔底水溶液進人脫水器，分離出水，所得粗順酐進人粗順酐罐。粗順酐進一步進人蒸餾塔進行蒸餾精制，得順酐。所得山東順酐可進行異構化得富馬酸和蘋果酸。
The mixture of benzene and air (benzene is 1% - 1.4%) is preheated by heat exchanger and then put into the tubular catalytic reactor. The oxidation reaction was carried out at the pressure of 0.1-0.2mpa and the temperature of 350-400 ℃. The product was cooled to the dew point (55-65 ℃) by two heat exchangers and one cooler. The cooled reactant enters the separator, and the crude maleic anhydride is obtained at the bottom of the separator and enters the crude maleic anhydride tank. The effluent from the top of the separator enters into the washing tower and is washed with water. The top of the tower is redundant air and unreacted benzene, which can be recovered by adsorption. The bottom water solution of the washing tower enters into the human dehydrator, the separated water, and the obtained crude maleic anhydride enters into the human crude maleic anhydride tank. Crude maleic anhydride is further distilled into a distillation tower to obtain maleic anhydride. The maleic anhydride can be isomerized to fumaric acid and malic acid.
2.C4餾分部分氧化制順酐
2. Partial oxidation of C4 fraction to maleic anhydride
工業上用不經分離的C4餾分或分離異丁烯和丁二烯后的C4餾分為原料順酐。C4餾分與空氣混合后進人流化床氧化反應器，在300―500℃溫度下，與反應器中的催化劑接觸順酐。氧化反應器頂部流出的反應生成物進人吸收塔，用水作為吸收劑，塔頂氣體經廢水
Maleic anhydride is produced from C4 fraction without separation or C4 fraction after separation of isobutylene and butadiene. C4 fraction is mixed with air and then enters the fluidized bed oxidation reactor. At 300-500 ℃, it contacts with the catalyst in the reactor to produce maleic anhydride. The reaction products from the top of the oxidation reactor enter the absorption tower, and water is used as the absorbent. The gas from the top of the tower flows through the waste water
